Spindle Helper – Oval or DD Spindle

Top Flange with an Oval or DD-shape Spindle

After clicking on the oval shape spindle in the PDF, follow these steps next.



Step 1

Choose the correct flow direction by clicking on the checkbox in de PDF file.

Step 2

At the bottom of the PDF-sheet, enter the outside diameter of the topflange (F)

Step 3

Enter the depth and width of the spindle (S and L)

Step 4

Enter the height of the spindle (A)

Step 5

Enter the BCD of the top flange

Step 6

enter the diameter of the topflange holes (E)

Step 7

Save the PDF and send it to Valveco.
